Model
Model
FY-3200MS/i4
Printhead
EPSON I3200/E1
Number of Printhead
4pcs
Print width
3200mm
Print Speed
| Print Speed | |
|---|---|
| 4 Pass | 100m²/h |
| 6 Pass | 85m²/h |
| 8PASS | 70m²/h |
Specification
Media Type
Banner,vinyl,mesh and other roll to roll outdoor printing material
Ink
Eco solvent ink
Media Type
High precision automatic elevated cleaning capping station for the perfect maintenance
Heating System
Front,middle and back heater, IR dryer,fan cooling system
RIP
United Fancy, Flexi PRINT, Maintop
Printer
AC220V 50HZ 1100W
Dryer
AC220V 50HZ 7200W
Platform heating
AC220V 50HZ 1800W
Features
01
High precision automatic elevated cleaning capping station for the perfect maintenance
02
2 individually controlled powerful dryer system, to start and stop automatically when a job starts or stops.
03
Cellular platform with a djustable vacuum control ,to move meida with different GSM easily and accurately
04
High sensitive crash sensor, to stop the carriage immeidately if hitting on any unexpected stuff while moving, so as to offer a last protection to printhead.
05
IGUS caterpillar chain,durable tomoveback andforthsilently withcables andtubeswell protectedinside
06
Double-roller plus tension bar for banner feeding system and twin-roll vinyl feeding system, with high sensitive diffuse reflection sensor to feed media with or without black back accurately.
07
Static-free pinch roller ,to feed media accurately for best print quality
08
Imported high quality guide, to move the carriage stably, smoothly and silently
09
2.5L main tank plus sub tanks, for long time fluent and sufficient ink flow.
Application
Indoor outdoor advertising
Decorative painting
Interior Decor
Studio photo
Display Stand
Background
